Product Description:
1.33kVA Deutz diesel generator is a three-phase system suitable for
a variety of industrial and commercial applications. With a rated
power of 33kVA, it is suitable for small and medium-sized power
needs, such as small factories, commercial facilities, construction
sites and emergency backup power supplies.Our company can also
provide you with high-power generators to power multiple
appliances.
2.The Deutz Diesel Generator Set comes with a 1 year or 1000 hours
warranty, ensuring that you are protected against any defects or
issues that may arise. This gives you peace of mind knowing that
your investment is protected and that you can rely on this
generator for years to come.
3.It is designed with a soundproof cover or other noise reduction
measures to reduce noise during operation, and is suitable for use
in places with strict requirements on noise.
4.This generator features an electric starting system, making it
easy to start up and get running quickly.
5.Please note that the Deutz Diesel Generator Set has a delivery
time of 30-35 days. This gives us time to prepare your generator
and ensure that it meets all of our strict quality control
standards before it is shipped to you.
6.Hosem A-DE33 Diesel Powered Generator Set is a reliable and
efficient solution for power supply in various industrial and
commercial settings.The generator set is manufactured in China and
is ISO9001 and CE certified, ensuring compliance with international
standards.
7.The Hosem A-DE33 diesel generator set is ideal for a variety of
applications and scenarios, including emergency power during power
outages, power supply in remote areas, and backup power for
hospitals, data centers, and other critical infrastructure. The
generator set is also ideal for use at construction sites, mining
operations, and oil and gas exploration sites.
8.If you are in need of a reliable and efficient diesel powered
generator, the Deutz Diesel Generator Set is an excellent choice.
With its water-cooled cooling system, 3 phase power, and electric
starting system, this generator is designed to provide you with the
power you need, when you need it. And with its 1 year or 1000 hours
warranty, you can rest assured that your investment is protected.
Technical Parameters:
| Generator Set Specification |
| Model | A-DE33 |
| Max. Power | kVA | 33 |
| kW | 26 |
| Rate Power | kVA | 30 |
| kW | 24 |
| Frequency | Hz | 50 |
| Rate Voltage | V | 400/230 |
| Rate Current | A | 43.3 |
| Fuel Tank Capacity | L | 60 |
| Dimension For Open-type Genset | mm | 1650 X 700 X 1250 |
| Weight For Open-type Genset | kg | 635 |
| Dimension For Soundproof Genset | mm | 2000 X 900 X 1250 |
| Weight For Soundproof Generator | kg | 885 |
| Noise Level for Soundproof Generator at 7M | dBA | 70 |
| Battery | One of Free Maintenance Battery |
Technical data--Engine
| Engine Specification |
| Engine Manufacturer | Deutz (Dalian) Engine Co., Ltd. |
| Engine Brand | Deutz |
| Engine Model | BFM3 G2 |
| No. of Cylinder | 4 Cylinder in line |
| Aspiration | Naturally aspirated |
| Governor | Mechanical |
| Engine Max. Output Power | kW | 32 |
| Displacement | L | 3.2 |
| Compression Ratio | 18.5 : 1 |
| Starting Voltage | V | 12 |
| Bore | mm | 98 |
| Stroke | mm | 105 |
| Lubrication Oil Capacity | L | 7.5 |
| Intake Air Flow | M3/Min | N.A. |
| Fuel Consumption at 100% Load | L/H | 7.7 |
Technical data--Controller
| Control Panel Specification |
| Controller Brand | Smartgen |
| Controller Model | HGM6120N |
| Breaker Brand | Delixi |
| Breaker Capacity (A) | 63 |
| Battery Charger | Smartgen Model BAC06A |
| Emergency Stop Button | Supply |
| Automatic Mains Fail (AMF) | Supply |
| Fuel Level | Supply |
| Automatic Transfer Switch | ATS as optional part |
| The control panel supply the full protection with alarm and
shutdown of the diesel generator include Start-up fault (generator
set shutdown), High coolant temperature (alarm and generator set
shutdown), Low oil pressure (alarm and generator set shutdown), Low
fuel level (alarm), Low cooling fluid level alarm (as optional),
Overload (alarm and generator set shutdown), Battery voltage high
(alarm). |
|
|
| Optional controller: Each model of Deepsea, Smartgen, ComAp brand
controller. |
Technical data--Alternator
| Alternator Specification |
| Alternator Manufacturer | Fuzhou Hosem Power Co., Ltd. |
| Alternator Model | ASF184GS |
| Alternator Brand | Hosem |
| Rate Output | kVA | 30 |
| Frequency | Hz | 50Hz |
| Altitude | M | ≤1000 |
| Insulation | Class H |
| Phase | 3 Phase |
| Working Temperature without power decrease | ≤40℃ |
| Working Altitude without power decrease | ≤1000m |
| Automatic Voltage Regulation | SX460 |
| Protection Grade | IP23 |
| Alternator for optional | Leroy Somer, Marathon, Mecc Alte and Hosem Brushless alternator for
optional |
|
FAQ:
Frequently Asked Questions for Hosem A-DE33 Deutz Diesel Generator
Set:
Q: What is the brand name of this diesel generator set?
A: The brand name of this diesel generator set is Hosem.
Q: What is the model number of this diesel generator set?
A: The model number of this diesel generator set is A-DE33.
Q: Where is this diesel generator set manufactured?
A: This diesel generator set is manufactured in China.
Q: What is the minimum order quantity for this diesel generator set?
A: The minimum order quantity for this diesel generator set is 1 set.
Q: What is the price of this diesel generator set?
A: The price of this diesel generator set is negotiable.
Q: How is this diesel generator set packaged for delivery?
A: This diesel generator set is packaged in a wooden package or
plastic foam package.
Q: How long does it take to deliver this diesel generator set?
A: It takes about 30 days to deliver this diesel generator set.
Q: What are the payment terms for this diesel generator set?
A: The payment terms for this diesel generator set are L/C and T/T.
