Continuous Power 60kVA Deutz Diesel Generator Set with Deutz Diesel
Engine BF4M2012 For Commercial
Deutz is one of world most famous engines from Germany and widely
acceptable all over the world. Hosem Power Deutz gensets are
ranging from 20kVA up to 1650kVA.
Specification of 60kVA Deutz Diesel Generator Set
| Model | A-DE66 |
| Max. Power | kVA | 66 |
| kW | 52.8 |
| Rate Power | kVA | 60 |
| kW | 48 |
| Frequency | Hz | 50 |
| Rate Voltage | V | 400/230 |
| Rate Current | A | 86.6 |
| Fuel Tank Capacity | L | 125 |
| Dimension For Open-type Genset | mm | 1850 X850 X 1250 |
| Weight For Open-type Genset | kg | 950 |
| Dimension For Soundproof Genset | mm | 2300 X900 X 1250 |
| Weight For Soundproof Generator | kg | 1250 |
| Noise Level for Soundproof Generator at 7M | dBA | 75 |
| Battery | Two of 80A Free Maintenance Battery |
Deutz Generator Sets are vastly used in transportation sector,
buildings, telecom, schools, hospitals, petrolube oil fields and
industrial power supplying area etc. With Deutz generating set
reliability, durability, flexibility, energy-saving, environment
protection and wonderful World wide after-service networks, Deutz
Generator Set act as a fundamental role in global gensets industry.
Specification of Deutz Alternator:
| Engine Manufacturer | Deutz (Dalian) Engine Co., Ltd. |
| Engine Brand | Deutz |
| Engine Model | BF4M2012 |
| No. of Cylinder | 4 Cylinder in line |
| Aspiration | Turbocharged & Aftercooled |
| Governor | Mech |
| Engine Max. Output Power | kW | 58 |
| Displacement | L | 4.0 |
| Compression Ratio | 19 : 1 |
| Starting Voltage | V | 24 |
| Bore | mm | 101 |
| Stroke | mm | 126 |
| Lubrication Oil Capacity | L | 8.5 |
| Fuel Tank Capacity | L | 125 |
| Fuel Consumption at 100% Load | L/H | 13.7 |
Use the one of the most famous brand Stamford alternator for the
60kVA Deutz diesel generator set. The Stamford alternator model UCI
224 E with brushless type, self-excitation with SX460 AVR.
Specification of Stamford Alternator:
| Alternator Manufacturer | Cummins Generator Technologies |
| Alternator Model | UCI 224 E |
| Alternator Brand | Stamford |
| Rate Output | kVA | 63 |
| Frequency | Hz | 50Hz |
| Altitude | M | ≤1000 |
| Insulation | Class H |
| Phase | 3 Phase |
| Working Temperature without power decrease | ≤40℃ |
| Working Altitude without power decrease | ≤1000m |
| Automatic Voltage Regulation | SX460 |
| Protection Grade | IP23 |
| Alternator for optional | Leroy Somer, Marathon, Mecc Alte and Hosem Brushless alternator for
optional |
|
The automatic control panel with one of most famous generator set
controller in China, Smartgen HGM6120N for the Deutz diesel
generator. supply the fully protection of diesel engine and
alternator. Delixi 125A MCCB for the power output of diesel
generator.
Specification of Control Panel:
| Controller Brand | Smartgen |
| Controller Model | HGM6120N |
| Breaker Brand | Delixi |
| Breaker Capacity (A) | 125 |
| Battery Charger | Smartgen Model BAC06A |
| Emergency Stop Button | Supply |
| Automatic Mains Fail (AMF) | Supply |
| Fuel Level | Supply |
| Automatic Transfer Switch | ATS as optional part |
| The control panel supply the full protection with alarm and
shutdown of the diesel generator include Start-up fault (generator
set shutdown), High coolant temperature (alarm and generator set
shutdown), Low oil pressure (alarm and generator set shutdown), Low
fuel level (alarm), Low cooling fluid level alarm (as optional),
Overload (alarm and generator set shutdown), Battery voltage high
(alarm). |
|
|
| Optional controller: Each model of Deepsea, Smartgen, ComAp brand
controller. |
FAQ:
Q: What the supply range of SDEC Diesel Generator?
A: The supply range from 25kVA to 1000kVA with 50Hz, and 25kVA to
413kVA for 60Hz.
Q: What the MOQ?
A: 1 Set.
Q: What the payment term?
A: 30% of total amount paid by T/T for deposit, and 70% of total
amount paid before shipment. Or the L/C payment.
Q: What the delivery time?
A: 20 Days for 1-3Units Order, 35days for 4-20Units Order.
Q: Which seaport you can ship the diesel generator to oversea
country?
A: We can ship the diesel generator from Fuzhou Port, China. And
Fuzhou port is a international seaport in China.
Q: What kind of the trade term you can offer?
A: We can offer with FOB, CNF, CIF or CIP.
Q: Do you have other voltage for optional?
A: Yes, we can customized made from 110V to 690V for client's
optional.
Q: How many kinds of the diesel generator you have for optional?
A: We have open-type, soundproof type, waterproof type and trailer
type diesel generator for optional.
Q: Does your generator have global warranty?
A: Yes. Gensets powered by global brand engine which with the
global warranty service. And the alterntors Stamford, Leroy somer,
Meccalte, Marathon also have the global warranty service.If you use
the Chinese brand diesel engine and alternator, we will undertake
the warranty, and during the warranty period, if there is any
quality problem, we will supply the spare parts to replacement
without charges. and the courier charges by air of spare parts will
be paid by us.
Q: Can you customized made the diesel generator?
A: Yes. Our generators can be customized depending on customers'
detailed requirements. We can supply diesel generators for rental
business, home use, inudstrial projects, army projects, power
station, etc. The diesel generators we supply are suitable for
indoor and outdoor use, lower and high temperature environment.
