Ricardo Generator , Silent Generator Ricardo Engine Generator ,
Ricardo Generator 100kVA For Bangladesh.
Generator Standard Compose:
- Ricardo Engine
- Meet the environmental temperature 40 ℃ water tank radiator,
Driving belt cooling fans, with fan safety shield
- 24 V charging generators
- Generator: Single bearing generator, IP23 Grading Protection, H
Insulation degree
- Shock absorber
- Dry air filter, Fuel filter, Oil filter
- Power output ABB circuit breaker
- Standard control panel
- 12 V battery and battery connection cables
- Battery Charger
- Exhaust pipe, Bellows, Flange, Muffler set
- Documents and Manuals
Specification of Ricardo Generator Set:
| Model | A-KF99 |
| Standby Power | kVA | 99 |
| kW | 79 |
| Prime Power | kVA | 90 |
| kW | 72 |
| Frequency | Hz | 50 |
| Output Voltage | V | 400/230 |
| Oil Consumption | L/H | 0.066 |
| Dimension For Open-type | mm | 1900 X 800 X 1450 |
| Weight For Open-type | kg | 1280 |
| Dimension For Soundproof | mm | 2900 X 1080 X 1500 |
| Weight For Soundprof | kg | 1820 |
| Noise For Soundproof | dBA | 75 |
| Engine Manufacturer | Shandong Kofo Power Co. Ltd. |
| Engine Brand | Kofo |
| Engine Model | R6105ZLDS1 |
| No.of Cylinder | 6 Cylinder in line |
| Bore | mm | 105 |
| Stroke | mm | 125 |
| Displacement | L | 6.49 |
| Aspiration | Turbocharger and After-cooled |
| Rate Speed | R.P.M. | 1500 |
| Governor | Mechanical |
| Lubrication Oil Capacity | L | 18 |
| Starting Voltage | V | 24 |
| Engine Max.Output Power | kW | 100 |
40unit Ricardo Generator in assemble
Specification of Alternator (Stamford Technologies)
| Alternator Manufacturer | Fuzhou Hosem Power Co., Ltd. |
| Alternator Brand | Hosem Power |
| Alternator Model | ASF224GL |
| Rate Output | kVA | 93 |
| Frequency | Hz | 50 |
| Altitude | M | ≤1000 |
| Insulation | Class H |
| Protection Grade | IP23 |
| Alternator for choice | We also have Leroy Somer, Marathon, Mecc Alte and Chinese brand
Brushless alternator for your choice. |
| Control Panel Model | AF500 |
| Controller | Smartgen Brand Model HGM6110N |
Controller
Smartgen control system integrating digital, intelligent and
network techniques is used for automatic control of diesel
generator set. It can carry out functions including automatic
start/stop, data measure and alarming.
The controller uses LCD display, optional Chinese and English
display interface with operation easy and reliable.
HT2000 control system uses micro-processing technique which can
carry out precision measure, constant value adjustment timing and
threshold setting and etc. of multi-parameters. It can be widely
used in all types of generator
automatic control for compact structure, advanced circuits, simple
connections and high reliability.
•High Temperature,low oil pressure,overspeed,
overcurrent,over/under voltage, over/under frequency protection.
•3 phase generator voltage and current measurement
•3 phase busbar voltage measurement
•3 phase power measurement
•3 analog inputs
•Event and performance log
•2 languages (user changeable)
Why Choose Hosem Power Generator?
Reasons1: We are More Professional
Most members of Hosem Power have more than 10 years of experience
in the generator area, Our mechanical engineers, electrical
engineers have more than 20 years of experience in the generator
ara. We are always ready to serve to your needs.
Reasons2: Outstanding Quality
Our advantage lies in:
1. Good shock absorption performance: Optimal design of shock
absorption system based on computer dynamic simulation.
2. Advanced control system: Full monitoring system control strategy
found on reliability design.
3. Low noise: Tailor custom-engineered exhaust silencer system for
each set.
4. Green environmental protection: Diesel generator set combined
energy-saving and low emission in one.
Reasons3: Strictly QC Before EX-Factory.
Each and every unit is strictly factory tested before shipment.
1) Parts faults testing
2) Fuel tank pressure testing
3) Bolt tightening torque testing
4) Painting thickness testing
5) Voltage bearing and insulation testing
6) Noise testing
7) Loading Testing: 25%, 50%, 75%, 100%, 110% load to check verify
that all control systems, alarm and shut-down protection.
FAQ
Q: Do you offer OEM service?
A: Yes
Q: What is your payment term?
A: 30% T/T in advance, 70% balance when receiving B/L copy, Or 100%
irrevocable L/C at sight.
Q: What is your lead time?
A: About 20-30 days after receiving advance deposit or original
L/C.
Q: What certificates do you have?
A: We have CE, ISO. And we can apply for specific certificates for
different countries such as SONCAP for Nigeria, COI for Iran, SASO
for Saudi Arabia, etc.
Q: What warranty do you provide?
A: One year, during the guarantee period, we will supply free of the easily damaged parts for the possible problems except for
the incorrect operation. After expiration, we supply cost spare parts for Genset maintenance.
