Cummins Diesel Geenrator, Cummins 500kW Diesel Generator Set,
Cummins Genset, Diesel Driven Generator
Key Feature of Cummins Diesel Generator:
(1).Full control panel with power indicator light and oil light.
(2).Emergency shutdown for low oil pressure and high water
temperature.
(3).Large fuel tank ensure continuous running.
(4).Compact structure.
(5).Reliable performance
(6).Free maintenance up to 1000 hours
(7).Easy for installation and .
(8).50Hz and 60Hz both are available for choice.
Specification:
| Model | A-C633 |
| Standby Power | kVA | 633 |
| kW | 506 |
| Prime Power | kVA | 575 |
| kW | 460 |
| Frequency | Hz | 50 |
| Output Voltage | V | 400/230 |
| Oil Consumption | L/H | 0.62 |
| Dimension For Open-type | mm | 3550 X 1600 X 2160 |
| Weight For Open-type | kg | 4950 |
| Dimension For Soundproof | mm | 4250 X 1550 X 2180 |
| Weight For Soundprof | kg | 5550 |
| Engine Manufacturer | Dongfeng Cummins Engine Co., Ltd. |
| Engine Model | KTAA19-G6 |
| No.of Cylinder | 6 Cylinder in line |
| Bore | mm | 159 |
| Stroke | mm | 159 |
| Displacement | L | 18.9 |
| Cooling Fan Air Flow | m3/min | 588 |
| Compress Air Flow | m3/min | 41.5 |
| Exhaust Gas Flow | m3/min | 111.3 |
| Exhaust Gas Temperature | ℃ | 450 |
| Lubrication Oil Capacity | L | 50 |
| Cooling Water Capacity | L | 91 |
| Starting Voltage | V | 24 |
| Engine Max.Output Power | kW | 570 |
| Alternator Manufacturer | Cummins Generator Technolgoies |
| Alternator Model | HCI 544 E |
| Alternator Brand | Stamford |
| Rate Output | kVA | 610 |
| Frequency | Hz | 50Hz |
| Altitude | M | ≤1000 |
| Insulation | Class H |
| Protection Grade | IP23 |
| Alternator for choice | We also have Leroy Somer, Marathon, Mecc Alte and Chinese brand
Brushless alternator for your choice. |
| Control Panel Model | AF500 |
| Controller | Deepsea Brand Model DSE7320 |
| Function of control panel | Automatic genset start/stop |
| Automatic battery charger |
| Emergency stop |
| AMF (Automatic Mains Fault) |
| Remote control |
| Micro-processor based design |
| LED alarm indication and Sound alarm |
| Display of the controller | Generator voltage: Uab, Ubc, Uca |
| Generator current: Ua, Ub, Uc |
| Generator temp.: ℃/℉ both display |
| Generator frequency: Hz |
| Generator power: kW, kVA, kWh, kVAr, kVArh, kVAh |
| Generator starts count: 999999 times (Max) |
| Generator pressure: kPa/Psi/Bar both display |
| Charging Voltage: V |
| Battery Voltage: V DC |
| Protection of Diesel Generator | Over / Under Speed Alarm and Shutdown |
| Start / Stop Failure Alarm |
| Over Current Alarm and Shutdown |
| Under / Over Generator Voltage Alarm and Shutdown |
| Low Oil Pressure Alarm and Shutdown |
| High Engine Temperature Alarm and Shutdown |
| Over Load Alarm and Shutdown |
| Low and High Battery Voltage Alarm |
| Lose of Speed Signal Alarm and Shutdown |
| Charge Fail Alarm |
Cummins Diesel Generator Feature:
1. Supply Cummins diesel generator output from 20kVA to 1875kVA;
2. Coupled with Stamford alternator, Marathon alternator or Chinese
brushless alternator;
3. The complete generator set is mounted as whole on a heavy-duty
fabricated, steel base frame;
4. Anti-vibration pads are fixed between the engine/alternator feet
and base frame;
5. Open type, silent type, super silent type or mobile type
generator;
6. CE, ISO9001-2008, SONCAP, SASO, and SGS certified;
7. Denyo type design soundproof canopy is no problem to supply;
8. Start system with maintenance-free battery;
9. Automatic start/stop system;
10. With 100% fire-resistant sound attenuating sponge for
soundproof canopy;
11. 10% of the rate output of overload for 1hours in every 12hours
12. Base fuel tank for at least 8 hours running;
13. The generating set can be lifted or carefully pushed/pulled by
the base frame;
14. Spare parts are easy to get from worldwide market with much
cheaper price;
15. ATS, Distribution panel, Parallel panel, Water heater, Daily
fuel tank, Remote control panel for optional;
16. Alternator for optional include Leroy Somer, Stamford,
Marathon, Mecc Alte and APT Power brand;
17. Controller for optional include Deepsea, ComAp, Smartgen and
Harsen brand;
18. Different brands of engine for optional, such as Perkins,
Deutz, Volvo, Doosan, Lovol, Weichai, Wandi and other famous brand
diesel engine generator set for optional, output from 10kVA to
3000kVA.
FAQ For Your Reference:
1. Q: What is your MOQ of this item?
A: 1 Set
2. Q: What is your payment terms?
A: Price is based on FCL sale: T/T, L/C, D/P, O/A
3. Q: What is the lead time?
A: 25-30 workings days
4. Q: Where is your port of loading?
A: Fuzhou, China.
5. Q: Can I use my own brand name?
A: Yes, OEM and ODM are both supported.
6. Q: Your annual production capactiy?
| Water-Cooled Genset | 3,000 units |
| Air-Cooled Genset | 100,000 units |
| GPU | 500 units |
7. Q: Available colors?
A: White, Blue, Red, Green, Yellow, Gray
8. Q: Which markets have you exported before?
A: Southeast Asia, the Middle East, Africa, Europe, North and South
America, Oceania.
9. Q: Any certifications for your gensets?
A: ISO9001-2008, ISO14001-2004, CE, SASO, SONCAP, RETIE, etc.
10. Q: How is your packaging?
A: Stretching film as standard, plywood crate is optional
11. Q: The valid period of the offer?
A: 30 DAYS
