Perkins Generator Set , 15kVA Perkins Gen-Set , Super Silent
Generators, Electric Diesel Generator
Perkins engine generator key feature:
Alternator (AC): Stamford, Leroy Somer, Marathon, and Hosem brushless alternators
1) Brushless, 4 poles, rotation magne;
2) IP21-23(NEMA1) enclose is standard for all industrial alternators;
3) H class insulation system;
4) AVR self-regulated, voltage regulation rate: ≤±1%;
5) Simple installation and maintenance with easy access to terminals,
rotating diodes and coupling bolts
Control panel: Manual or digital control panel(with AMF function), viareis brand
for option; ATS can be option
1) Auto start when power goes out .Auto stop when power comes back
on;
2) Worldwide technical support with programmable software download;
3) Full online documentation;
4) Trouble shooting symbols to assist owner on concerns with the
generator
Type: silent type with canopy to reduce the noise level and Open frame
without canopy for option
Fuel tank: 8-10 hours in normal, can be custmised
Other:
1) Power Factor: 0.8(lagging) ;
2) Model of Connection: 3 phase 4 lines;
3) Frequency Drop(%): ≤ 0.5;
4) Transient state frequency deviation(%): (advertised power )
+10~-7;
5) Frequency Recovery Time(S): ≤ 3;
6) Voltage Recovery Time(S): ≤ 4;
7) Waveform Distortion(%): ≤ 5
Specification:
| Model | A-P17 |
| Standby Power | kVA | 17 |
| kW | 13 |
| Prime Power | kVA | 15 |
| kW | 12 |
| Frequency | Hz | 50 |
| Output Voltage | V | 400/230 |
| Oil Consumption | L/H | 0.07 |
| Dimension For Open-type | mm | 1565 X 730 X 1200 |
| Weight For Open-type | kg | 423 |
| Dimension For Soundproof | mm | 1750 X800 X 1150 |
| Weight For Soundprof | kg | 603 |
| Engine Manufacturer | Perkins U.K. |
| Engine Brand | Perkins |
| Engine Model | 403A-15G2 |
| No.of Cylinder | 3 Cylinder in line |
| Bore | mm | 84 |
| Stroke | mm | 80 |
| Displacement | L | 1.49 |
| Cooling Fan Air Flow | m3/min | 130 |
| Compress Air Flow | m3/min | 1.1 |
| Exhaust Gas Flow | m3/min | 2.7 |
| Exhaust Gas Temperature | ℃ | 445 |
| Lubrication Oil Capacity | L | 6 |
| Cooling Water Capacity | L | 6 |
| Starting Voltage | V | 12 |
| Engine Max.Output Power | kW | 11.2 |
| Alternator Manufacturer | Cummins Generator Technologies |
| Alternator Brand | Stamford |
| Alternator Model | PI 044G |
| Rate Output | kVA | 15 |
| Frequency | Hz | 50Hz |
| Altitude | M | ≤1000 |
| Insulation | Class H |
| Protection Grade | IP23 |
| Alternator for choice | We also have Leroy Somer, Marathon, Mecc Alte and Chinese brand
Brushless alternator for your choice. |
| Control Panel Model | AF500 |
| Controller | Deepsea Brand Model DSE7320 |
| Function of control panel | Automatic genset start/stop |
| Automatic battery charger |
| Emergency stop |
| AMF (Automatic Mains Fault) |
| Remote control |
| Micro-processor based design |
| LED alarm indication and Sound alarm |
| Display of the controller | Generator voltage: Uab, Ubc, Uca |
| Generator current: Ua, Ub, Uc |
| Generator temp.: ℃/℉ both display |
| Generator frequency: Hz |
| Generator power: kW, kVA, kWh, kVAr, kVArh, kVAh |
| Generator starts count: 999999 times (Max) |
| Generator pressure: kPa/Psi/Bar both display |
| Charging Voltage: V |
| Battery Voltage: V DC |
| Protection of Diesel Generator | Over / Under Speed Alarm and Shutdown |
| Start / Stop Failure Alarm |
| Over Current Alarm and Shutdown |
| Under / Over Generator Voltage Alarm and Shutdown |
| Low Oil Pressure Alarm and Shutdown |
| High Engine Temperature Alarm and Shutdown |
| Over Load Alarm and Shutdown |
| Low and High Battery Voltage Alarm |
| Lose of Speed Signal Alarm and Shutdown |
| Charge Fail Alarm |
FAQ For Your Reference:
Q: What is your MOQ of this item?
A: 1 Set
Q: What is your payment terms?
A: Price is based on FCL sale: T/T, L/C, D/P, O/A
Q: What is the lead time?
A: 25-30 workings days
Q: Where is your port of loading?
A: Fuzhou, China.
Q: Can I use my own brand name?
A: Yes, OEM and ODM are both supported.
Q: Your annual production capactiy?
| Water-Cooled Genset | 3,000 units |
| Air-Cooled Genset | 100,000 units |
| GPU | 500 units |
Q: Available colors?
A: White, Blue, Red, Green, Yellow, Gray
Q: Which markets have you exported before?
A: Southeast Asia, the Middle East, Africa, Europe, North and South
America, Oceania.
Q: Any certifications for your gensets?
A: ISO9001-2008, ISO14001-2004, CE, SASO, SONCAP, RETIE, etc.
Q: How is your packaging?
A: Stretching film as standard, plywood crate is optional
Q: The valid period of the offer?
A: 30 DAYS
