Isuzu Diesel Generator 20kW , 25kVA , Isuzu China 4JB , JE493DB-02
, China Soundproof Generator
Specifiation:
| Generator Set Specification |
| Model | A-I44 |
| Max. Power | kVA | 44 |
| kW | 35 |
| Rate Power | kVA | 40 |
| kW | 32 |
| Frequency | Hz | 50 |
| Rate Voltage | V | 400/230 |
| Rate Current | A | 57.7 |
| Dimension For Open-type Genset | mm | 1350 X 750 X 1050 |
| Weight For Open-type Genset | kg | 570 |
| Dimension For Soundproof Genset | mm | 1800 X 850 X 1200 |
| Weight For Soundproof Generator | kg | 880 |
| Noise Level at 7 Meters | dBA | 70 |
| Fuel Tank Capacity | Litres | 80 |
| Battery | One of 80A Free Maintenance Battery |
| Engine Specification |
| Engine Manufacturer | Jiangxi Isuzu Motors Co., Ltd. |
| Engine Brand | Isuzu |
| Engine Model | JE493ZLDB-02 |
| No. of Cylinder | 4 Cylinder in line |
| Aspiration | intercooling turbo |
| Governor | Mechanical |
| Engine Max. Output Power | kW | 38 |
| Displacement | L | 2.7 |
| Starting Voltage | V | 12 |
| Bore | mm | 93 |
| Stroke | mm | 102 |
| Lubrication Oil Capacity | L | 5.6 |
| Compression Ratio | 18.2 : 1 |
| Intake Air Flow | M3/Min | N.A. |
| Fuel Consumption at 100% Load | L | 8.83 |
Hosem Isuzu series silent generator set, equipped with original
Japanese Isuzu diesel engine JE493ZLDB-02, rated power 32kW/ 40kVA. Isuzu generators have many advantages,
such as low noise levels, small vibration, and low fuel
consumption.
Other advantages of 40kVA Isuzu Diesel Generator Set
1. Compact structure, small size, light weight, easy to transport
2. Strong power, low fuel consumption, small vibration, low
emissions, in line with the national environmental protection
requirements
3. Excellent durability, long operation life, overhaul cycle more
than 10000 hours;
4. Simple operation, easy access to spare parts, low maintenance
cost,
5. The product has high reliability and the maximum ambient
temperature can reach 60 ℃
6. Global service network, convenient service.
Standard Features:
Excitation system: self-excited (AREP and PMG are optional)
• ATS (automatic transfer switch) receptacle (optional)
• Lockable battery isolator switch
• Stainless galvanized zinc plates with strong
corrosion resistance (Optinal)
• Vibration isolators between the engine/alternator
and base frame
• Integrated wiring design
• Base fuel tank for at least 8 hours running
• Equipped with an industrial muffler
• Engine oil pump
• 50℃ radiator
• Top lifting and steel base frame with forklift holes
• Drainage for fuel tank
• Complete protection functions and safety labels
• IP54 (soundproof sets), IP56 (control system)
• Water jacket preheater, oil heater and double air
cleaner, etc. are available.
Contact Us:
FQA
Question:
What's your delivery time?
Answer:
Our delivery time is 35days after receiving your deposit
Question:
What's your warranty?
Answer:
We provide 1 year or 1000 hours warranty to our industrial and
marine generator
Question:
Do you provide OEM or ODM service?
Answer:
Yes, in Hosem Power, we have an R&D department which
professional in resolving any tailored needs of our Customers, OEM
and ODM are available.
