C 400Hz Diesel Generator Set , Powered by Cummins Engine, Silent Type 400Hz Generator for Military

400Hz ALTERNATOR

• Double bearing , the alternator can be extract with a forklift without disassemble the canopy or the control board.
• Voltage: 115/200Vac
• Frequency: 400Hz
• Rated speed 1500 r.p.m
• Self-excited and self-regulated

• Voltage index

- Voltage Adjust Ratio: 1% from no load to full load;

- Voltage Modulation: ≤2.5V;

- Under the balance load, the phase voltage shifting 120°±4°

- Distortion Factor: ≤ 0.05

- Wave Crest Factor: 1.31-1.51；

- Phase Voltage Adjustment Range in No Load: 115±12V

- Voltage Un-balance: 3V RMS Maximum

- Transient State Voltage Recover Time Conform to MIL-STD 704E Chart 4 standard, phase voltage transient state peak voltage range: 80 - 180 V, Steady voltage range 108 - 118 V.

- Inner wiring voltage drop compensate maximum 5% (adjustable).

• Frequency standard
  • Frequency: 400Hz;
  • Steady Frequency Range: 393-407Hz;
  • Frequency Steady Time: according MIL-STD-704E chart 5.
  • Frequency Modulation: ＜4Hz

• AC Protection System
  • Over Voltage Trip: Voltage exceed 126V (110% of rate voltage), delay 1-2seconds
  • Low Voltage Trip: Voltage Lower than 101V(88% of rate voltage), delay 7 seconds
  • Over Frequency: Frequency Exceed 430Hz, delay 2-5 seconds, trip
  • Low Frequency: Frequency lower 370Hz, delay 1-3 seconds, trip
  • Over Load: 125% of rate load for 5minutes, trip.

Fuzhou Hosem Power Co., Ltd. is one of the most famous diesel generator manufacturers in China. The Hosem brand generator set output range from 3kVA to 3000kVA with frequency at 50Hz or 60Hz, the voltage of the diesel generator from 110kVA to 690V for client options.

The diesel generator powered by Cummins diesel engine, Deutz diesel engine, Perkins diesel engine, Volvo diesel engine, Fawde diesel engine, Yuchai diesel engine, Ricardo diesel engine and other famous brand diesel engine, Coupled with Stamford alternator, Leroy Somer alternator, Marathon alternator, Mecc Alte alternator and Hosem brand alternator for optional.

Hosem Power uses the most famous brand controller for our diesel generator, include Deepsea brand with model DSE7320, DSE6020 and DSE7420 controller, ComAp brand with model MSR10, AMF25, Nano and IC-NT controller, Smartgen brand with HGM6110, HGM6120, HGM7110, HGM7210 and other models.

Hosem Power can supply the open-type industrial generator, marine generator, natural gas generator, biogas generator, soundproof diesel generator, trailer diesel Generator and Ground Power Unit. The Hosem Power diesel generators are widely used in the Island as the continuing power, hospital, highway, airport, factories and big mall.

We supply one year or 1000 working hours warranty for all of our generator set.
