63kva 50kw 60Hz 4BTA3.9-G2 Engine Cummins Generator Set Silent 50kw

Ask Lasest Price
Brand Name :	Hosem Power
Model Number :	A-C69HS
Certification :	CE/ISO9001
Payment Terms :	L/C, T/T
Supply Ability :	500 unit per month
Delivery Time :	30 days

Add to Cart

Product Details
Company Profile

63kva 50kw 60Hz 4BTA3.9-G2 Engine Cummins Generator Set Silent 50kw

63kva 50kw silent electric diesel generator set by 60Hz Cummins 4BTA3.9-G2 engine

Generator Set Specification
Model		A-C69HS
Max. Power	kVA	69
Max. Power	kW	55.2
Rate Power	kVA	63
Rate Power	kW	50
Frequency	Hz	60
Rate Voltage	V	220/127
Rate Current	A	164.0
Dimension For Open-type Genset	mm	1820 X 750 X 1050
Weight For Open-type Genset	kg	2500 X 1050 X 1490
Dimension For Soundproof Genset	mm	70
Weight For Soundproof Generator	kg	350

Engine Specification
Engine Manufacturer		Dongfeng Cummins Engine Co., Ltd.
Engine Brand		Cummins
Engine Model		4BTA3.9G2
No. of Cylinder		4 Cylinder in line
Aspiration		Turbocarged & Aftercooed
Governor		Electric
Engine Max. Output Power	kW	66
Displacement	L	3.9
Starting Voltage	V	24
Bore	mm	102
Stroke	mm	120
Lubrication Oil Capacity	L	11

Alternator Specification
Alternator Manufacturer		Cummins Generator Technologies
Alternator Model		UCI 224 D
Alternator Brand		Stamford
Rate Output	kVA	65
Frequency	Hz	60Hz
Altitude	M	≤1000
Insulation		Class H
Voltage Regulation		AVR Model SX460
Protection Grade		IP23
Alternator for optional	Leroy Somer, Marathon, Mecc Alte and Hosem Brushless alternator for optional

Control Panel Specification
Controller Brand	Deepsea
Controller Model	DSE7320
Breaker Brand	Delixi
Breaker Capacity	80A
Battery Charger	Supply
Emergency Stop Button	Supply
Automatic Mains Fail (AMF)	Supply
The control panel supply the full protection with Alarm and Shutdown of the diesel generator include High Temp, Low Oil Pressure, Over / Under Speed, Over Load, Start / Stop Fail, Under / Over Voltage etc.


Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller.

Product Description

Δ Main Features

1. Cooperate with Cummins which is a world brand with a global warranty.
2. Genset design: Open, Supper silent, Soundproof, Trailer and container type.
3. Reliable quality with fewer failures and less maintenance.
4. Integrated design, prevents oil leakage, and greatly reduces the failure rate.
5. Intake preheating, better-starting performance, and faster acceleration.
6. Cooperate with Leroy Somer, Mecc Alte, and Stamford.
7. Optional manual and ATS control panels
8. Optional air filter, fuel filter, and oil filter
9. Comply with CE and ISO standards
10. All generator sets are gone through strict testing before being shipped, including 25% load, 50% load, 75% load, 100% load, and all protection functions (over speed stop, high water temperature, low oil pressure, battery charging fail, emergency stop)

Δ FAQ

Q1: What is the power range of your diesel generator?
A: We can provide power from 0.7kVA-2000kVA.

Q2: The valid period of the offer?

A: 30 days.

Q3: What is the exact address of your factory?

A: Our company is located in C2 Building, Cangshan Wanda Plaza, No. 216 Pushang Road, Fuzhou City, Fujian, China.

Q4: Which trade term can you accept?

A: Available trade terms: FOB, CIF, CFR, EXW, etc.
