    Silent Diesel Generator Set 50kVA 40kW Soundproof Deutz Engine Generator Commercial

    Ask Lasest Price
    Brand Name : Hosem Power
    Model Number : A-DE55S
    Certification : CE/ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 500 unit per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Silent Diesel Generator Set 50kVA 40kW Soundproof Deutz Engine Generator Commercial

    Silent Diesel Generating Set 50kVA 40kW Soundproof Deutz Engine Commercial Use


    Generator Set Specification
    ModelA-DE55S
    Max. PowerkVA55
    kW44
    Rate PowerkVA50
    kW40
    FrequencyHz50
    Rate VoltageV400/230
    Rate CurrentA72.2
    Fuel Tank CapacityL100
    Dimension For Open-type Gensetmm1750 X 700 X 1250
    Weight For Open-type Gensetkg695
    Dimension For Soundproof Gensetmm2000 X 900 X 1250
    Weight For Soundproof Generatorkg945
    Noise Level for Soundproof Generator at 7MdBA70
    BatteryOne of Free Maintenance Battery

    Engine Specification
    Engine ManufacturerDeutz (Dalian) Engine Co., Ltd.
    Engine BrandDeutz
    Engine ModelBFM3C
    No. of Cylinder4 Cylinder in line
    AspirationTurbocharger, after-cooled
    GovernorElectric
    Engine Max. Output PowerkW50
    DisplacementL3.2
    Compression Ratio18.5 : 1
    Starting VoltageV12
    Boremm98
    Strokemm105
    Lubrication Oil CapacityL7.5
    Intake Air FlowM3/MinN.A.
    Fuel Consumption at 100% LoadL/H11.2

    Alternator Specification
    Alternator ManufacturerFuzhou Hosem Power Co., Ltd.
    Alternator ModelASF224D
    Alternator BrandHosem
    Rate OutputkVA50
    FrequencyHz50Hz
    AltitudeM≤1000
    InsulationClass H
    Phase3 Phase
    Working Temperature without power decrease≤40℃
    Working Altitude without power decrease≤1000m
    Automatic Voltage RegulationSX460
    Protection GradeIP23
    Alternator for optionalLeroy Somer, Marathon, Mecc Alte and Hosem Brushless alternator for optional

    Control Panel Specification
    Controller BrandSmartgen
    Controller ModelHGM6120N
    Breaker BrandDelixi
    Breaker Capacity (A)100
    Battery ChargerSmartgen Model BAC06A
    Emergency Stop ButtonSupply
    Automatic Mains Fail (AMF)Supply
    Fuel LevelSupply
    Automatic Transfer SwitchATS as optional part
    The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm).
    Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller.

    Product Description

    Δ Main Features

    1. Set mounted with Delix brand Circuit Breaker.
    2. Anti-vibration mountings during engine, alternator, and base frame.
    3. Industrial silencers with flexible connects and elbows.
    4. Radiator with the engine-driven fan mounted on the skid
    5. Alternator brands: Stamford, Leroy Somer, Marathon, Mecc Alte.
    6. System Options: ATS system, remote control system, parallel operation system.
    7. Control panel : Smartgen , Deepsea, ComAp.
    8. We offer options generators as the below shows:
    A. 50Hz and 60Hz both are available for choice.
    B. Voltage: we offer 127/220V, 133/230V, 220/380V, 230/400V, etc. or depending on your request.
    9. As backup power: The Deutz 50kva diesel generator is often used as a backup power source in case of power outages or other disruptions. We have ATS for optional can be connected to an automatic transfer switch, which will automatically turn it on when the main power supply fails.
    10. Remote power: The Deutz 50kva diesel generator can be used to provide power in remote locations where electrical infrastructure is not available or reliable.



    Δ FAQ


    Q1: Is it all right to make the customer's own brand name?
    A: We can be your OEM manufacturer with your authorization of the brand.


    Q2: Can you accept OEM orders?
    A: Yes, we have a professional design team and sincerely welcome OEM orders.


    Q3: The valid period of the offer?
    A: Usually 30 days.


    Q4: Where is your Loading Port?
    A:FUZHOU MAWEI PORT,CHINA.
